Nonwoven Double Cylinder Double Carding Machine/Fiber Carding Machine

Nonwoven Double-Cylinder Double-Doffer Carding Machine/Fiber Carding Machine

Specifications:

Description:

• Function and characteristics
• This machine is used for fully carding the fiber batt following opening and blending ,then forming parallel or random web through doffer and random if required ,which is then supplied to the next processes
• The company produces carding machines to cover all types of fiber, synthetic and natural fibers ect. From very fine to very coarse deniers ,fiber length up to 120mm
• Card with cylinders up to 1.5meters in diameter and up to 2.5meters in width are produced as normal standard
• Card main cylinders are balanced to a surface speed of 1500meters //min ,output speed up to 80m/min ,web weight 12-60g/m2
• Card capacity is depending upon card type ,fiber denier ,types of fiber but can be excess of 800 kg/h
• All types of card both single and double doffers can be fitted with randomizer rollers or not dependent on customer’s needs
• All drives including main drive ,doffers , workers , feed rolls ect. Are variable speed . Metal detection devices are standard on feed rolls
• Card wires can be supplied as surface wound or interlocking as required
• The multi-point suction system ensures all free fiber and dust is continuously removed from the card to be recycled or fed another recycling process
