Mattress Thermobonding Electric Drying Oven For Fiberfill 3x12m

Mattress Thermobonding Electric Drying Oven For Fiberfill 3x12m

Mattress Thermobonding Electric Drying Oven For Fiberfill 3x12m

Product Details:

Place of Origin: China
Brand Name: HongYi
Certification: ISO9001/CE
Model Number: HYHX

Payment & Shipping Terms:

Minimum Order Quantity: 1set
Price: negotiation
Packaging Details: Packed in carton firstly,and then reinforced with wooden case for outer packing
Delivery Time: 10 working days after received your payment
Payment Terms: L/C, T/T, Western Union
Supply Ability: 2 sets per month
Contact Now
Detailed Product Description
Product Name: Oven Width: 3000-12000mm
Temp.: 220c



Changshu CE/ISO9001 3x12m nonwoven mattress thermo-bonded drying oven





Specifications:

Frame width :1700-2500mm

Capacity :500kg/h

Installed power :9.3kw

Self-carried reserve chute with controllable height

Inverter controlled output device and adjustable output speed

Adjustable output thickness ranging from 80-150mm according to productivity

The machine is used to process the batt of fiber to obtain a hard and thick thermal-bonding wadding.The low melt fiber will combine other fibers together through hot air penetration and colling system for reinforcement.

Main specifications

Working width ≤5000mm

Product weight (60-1500)gram/㎡

Product thickness (3-200)mm

Surface temp. ≤220℃

Heating method hot oil circulation, electricity heating, direct burning

Oven working width 6.0m 8.0m 10m

Structure

-Single layer,single belt or double-belt structure

-Up and down belts hold the web for entering to get heated and formed.

-High temperrature resistance TEFLON belt with auto correction device.

-Main drive and fan inverter controlling.
